Parameter Category |
BLF-A503 |
BLF-A504 |
BLF-A506 |
BLF-A508 |
Product Model |
BLF-A503 |
BLF-A504 |
BLF-A506 |
BLF-A508 |
Supported Dental Chairs |
15-20 units |
20-30 units |
30-40 units |
40-60 units |
Input Power Supply |
380V/50Hz |
380V/50Hz |
380V/50Hz |
380V/50Hz |
Rated Power |
7.5KW |
10kW |
15kW |
20kW |
Control Mode |
Pressure Sensing |
Pressure Sensing |
Pressure Sensing |
Pressure Sensing |
Start/Stop Pressure |
5/8bar (Adjustable) |
5/8bar (Adjustable) |
5/8bar (Adjustable) |
5/8bar (Adjustable) |
Air Tank Capacity |
300L |
300L |
600L |
1000L |
Air Flow Rate (@5bar) |
840L/min |
1120L/min |
1680L/min |
2240L/min |
Noise Level |
70dB(A) |
70dB(A) |
71dB(A) |
73dB(A) |
Overall Dimension (lbh) |
890×700×1618mm |
1280×700×1260mm |
1280×700×1618mm |
1730×700×1618mm |
Net Weight |
245kg |
285kg |
390kg |
515kg |
Drainage System |
Automatic Drainage |
Automatic Drainage |
Automatic Drainage |
Automatic Drainage |
Air Treatment Method |
Refrigerated Dryer + Precision Filtration |
Refrigerated Dryer + Precision Filtration |
Refrigerated Dryer + Precision Filtration |
Refrigerated Dryer + Precision Filtration |
